Product Overview: ADG713BRUZ-REEL7

The ADG713BRUZ-REEL7 is a high-performance, CMOS analog multiplexer from Analog Devices Inc. This precision device is part of a series that offers significant improvements in performance over previous generations of CMOS multiplexers. With its robust design and advanced technology, the ADG713BRUZ-REEL7 is an ideal choice for a wide range of applications, including data acquisition systems, communication systems, and medical equipment.

Key Features

• Low On Resistance: The typical on resistance is only 4 ohms, which ensures minimal signal distortion and allows for high-quality signal switching.
• Single-Supply Operation: This device operates from a single 3 V to 5 V power supply, making it suitable for battery-powered and portable devices.
• Low Power Consumption: The ADG713BRUZ-REEL7 boasts a very low power consumption, with a typical power dissipation of less than 0.01 µW, which is critical for power-sensitive applications.
• Dual 4:1 Multiplexer Configuration: It features a dual 4:1 multiplexer configuration, which allows for flexible signal routing within a circuit.
• Fast Switching Times: The device offers fast switching times (t<sub>ON and t<sub>OFF) of typically 20 ns, enabling quick signal changes and efficient data throughput.
• Enhanced ESD Protection: It is equipped with enhanced electrostatic discharge (ESD) protection, which safeguards the device against damage from static electricity.

Applications

The ADG713BRUZ-REEL7 is versatile and can be used in various applications, including:

• Automated Test Equipment (ATE)
• Data Acquisition Systems
• Audio and Video Switching
• Sample-Hold Systems
• Communication Systems
• Medical Equipment

Packaging and Quality

Supplied in a compact TSSOP-16 package, the ADG713BRUZ-REEL7 is designed for space-constrained applications. The device is provided in tape and reel packaging, denoted by the suffix 'REEL7', which facilitates automated assembly processes and mass production. Analog Devices Inc. ensures the highest quality and reliability of its products, and the ADG713BRUZ-REEL7 is no exception, meeting stringent industry standards for performance and durability.
