Analog Devices Inc. ADG5404BRUZ High-Performance Analog Multiplexer

The ADG5404BRUZ is a robust, high-performance analog multiplexer brought to you by Analog Devices Inc., a company renowned for its precision engineering and innovative design in the field of semiconductor technology. This particular component is part of the ADG5404 series, which is designed to facilitate the routing of analog signals in a wide array of applications, including data acquisition systems, medical equipment, and industrial process controls.

The ADG5404BRUZ offers four single-pole/double-throw (SPDT) switches, providing the versatility needed for complex signal routing tasks. The device operates with a dual supply voltage ranging from ±10.8 V to ±16.5 V or a single supply voltage from 10.8 V to 33 V. This wide range of operating voltages makes the ADG5404BRUZ suitable for accommodating various system requirements.

One of the standout features of the ADG5404BRUZ is its low on-resistance (typically 4.5 Ω), which ensures minimal signal distortion and power loss. The on-resistance is also matched between channels to within 0.2 Ω and remains flat over the full analog signal range, providing excellent linearity and low signal attenuation.

Moreover, the ADG5404BRUZ boasts a high level of integration, which simplifies design and reduces board space requirements. It comes in a compact 20-lead TSSOP (Thin Shrink Small Outline Package) that offers a space-saving solution for dense circuit boards. The device also features overvoltage protection up to ±55 V at the source and drain pins, safeguarding the multiplexer against unexpected voltage spikes that can occur in harsh environments.

For applications requiring low leakage currents, the ADG5404BRUZ excels with its low off-leakage current (typically less than 0.1 nA at 25°C), ensuring high signal integrity and accuracy. Furthermore, the multiplexer is equipped with a 3 V logic-compatible digital interface, making it easy to control via standard microcontrollers or digital logic circuits.

In summary, the ADG5404BRUZ from Analog Devices Inc. is a reliable and efficient solution for designers seeking a high-quality analog multiplexer with robust protection features and excellent electrical characteristics. Its performance and integration make it an ideal choice for a broad range of demanding applications.
