The ADG413BR from Analog Devices Inc. is a high-performance, precision monolithic quad SPST (single pole single throw) switch. This component is designed to provide superior switching performance for a wide range of applications, including data acquisition systems, communication systems, and process controls.

Key Features

• Low On Resistance: The ADG413BR boasts a low on resistance (typically 35 ohms), which ensures minimal signal distortion and power loss across the switch.
• Low Power Consumption: With a power consumption of less than 1µW, this device is ideal for power-sensitive applications.
• Single 5 V to ±15 V Supply: The switch operates efficiently across a wide range of supply voltages, adding to its versatility in different circuit environments.
• Fast Switching Times: It offers fast transition times (t_ON of 175 ns and t_OFF of 145 ns), making it suitable for applications requiring quick signal switching.
• Enhanced Signal Integrity: The ADG413BR features low charge injection, low power dissipation, and a low leakage current, ensuring high signal integrity.
• Break-Before-Make Switching: This functionality prevents momentary shorting when switching channels, which is critical for preventing damage to sensitive components.

Applications

The ADG413BR is utilized across various applications due to its robust design and reliable performance. Some typical applications include:

• Sample-Hold Systems
• Analog Multiplexing/Demultiplexing
• Audio Signal Routing
• Video Signal Routing
• Communication Systems
• Avionics and Military Systems

With its precision and low power consumption, the ADG413BR is an excellent choice for designers seeking a switch that offers both high performance and reliability. Analog Devices Inc. has a long-standing reputation for creating high-quality components, and the ADG413BR is no exception, providing the consistency and durability that engineers require for their sophisticated electronic systems.
