ADG1207YRUZ by Analog Devices Inc.

The ADG1207YRUZ is a high-performance, low-voltage, 8-channel multiplexer from Analog Devices Inc. This advanced component is designed to operate with a single +5 V to +16.5 V power supply, or with dual ±5 V to ±16.5 V supplies, making it an exceptionally versatile choice for a wide range of applications. The ADG1207YRUZ offers a robust feature set that ensures reliable performance in even the most demanding environments.

Constructed with Analog Devices Inc.'s proprietary iCMOS® technology, the ADG1207YRUZ achieves an optimal balance between power consumption and speed. This technology also provides enhanced electrostatic discharge (ESD) protection, which significantly increases the device's longevity and durability. The multiplexer's on-resistance profile is flat over the full analog input range, ensuring excellent linearity and low distortion. This makes the ADG1207YRUZ an ideal choice for precision data acquisition systems and other applications requiring high signal integrity.

The ADG1207YRUZ boasts a low on-resistance of typically 4.5 Ω, which remains consistent over the full signal range. Additionally, the device exhibits a low on-resistance match between channels and a very low total harmonic distortion (THD), further enhancing its performance in audio and other signal routing applications. Fast switching times of tON 60 ns and tOFF 30 ns, combined with a low charge injection of 10 pC, make the ADG1207YRUZ suitable for sample-and-hold circuits and programmable logic controllers (PLCs) where speed is crucial.

Furthermore, the ADG1207YRUZ features a 3 V logic-compatible digital input, which simplifies interfacing with modern microprocessors and digital logic. The package is a TSSOP-16 (thin shrink small outline package), which offers a compact footprint for space-constrained applications. For ease of use, the device includes a break-before-make switching action, which prevents momentary shorting when switching channels.

With its robust design, precise performance, and flexible power supply options, the ADG1207YRUZ from Analog Devices Inc. is a top-tier solution for designers seeking a reliable and efficient multiplexer for their electronic systems.
