AD828ARZ-REEL7

Part No AD828ARZ-REEL7
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Video Amps and Modules
Description IC VIDEO OPAMP DUAL LP 8-SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Applications Voltage Feedback
Number of Circuits 2
-3db Bandwidth 130MHz
SR - Slew Rate 450 V/μs
Operating Supply Current 14mA
Output Current per Channel 50mA
Dual Supply Voltage (±) 5 V ~ 36 V, ±2.5 V ~ 18 V
Mounting SMD
Package 8-SOIC (0.154", 3.90mm Width)
Manufacturer Package 8-SOIC
Manufacturer Homepage www.analog.com
Win Source Part Number 713350-AD828ARZ-REEL7
Popularity Medium
Supply and Demand Status Balance
Family Name AD828
Introduction Date September 09, 1996
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian AD828ARZ-REEL7 CAD Model

Description

The AD828ARZ-REEL7 is a dual, high-speed, low-power video amplifier from Analog Devices Inc. It is a voltage feedback amplifier with a gain bandwidth product of 100 MHz and a 3 dB bandwidth of 130 MHz. It has an input bias current of 6.6 µA and an input offset voltage of 2 mV. The AD828ARZ-REEL7 can operate on a single supply voltage of 5 V to 36 V or a dual supply voltage of ±2.5 V to ±18 V. It has a power supply rejection ratio (PSRR) of 80 dB and a common mode rejection ratio (CMRR) of 82 dB. The AD828ARZ-REEL7 is housed in an SOIC-8 package.

The AD828ARZ-REEL7 is ideal for a wide range of video applications, including:

  • Video distribution
  • Video processing
  • Video cameras
  • Video monitors
  • Video projectors
  • Medical imaging
  • Industrial inspection

The AD828ARZ-REEL7 is a low-power video amplifier, making it ideal for battery-powered applications. It also has a wide operating temperature range of -40°C to +85°C, making it suitable for use in harsh environments.

Here is a more detailed description of some of the key features of the AD828ARZ-REEL7:

  • High speed: The AD828ARZ-REEL7 has a gain bandwidth product of 100 MHz and a 3 dB bandwidth of 130 MHz. This makes it ideal for amplifying high-frequency video signals.
  • Low power: The AD828ARZ-REEL7 has a typical operating supply current of 14 mA. This makes it ideal for battery-powered applications.
  • Wide operating temperature range: The AD828ARZ-REEL7 has a wide operating temperature range of -40°C to +85°C. This makes it suitable for use in harsh environments.
  • Low distortion: The AD828ARZ-REEL7 has a total harmonic distortion (THD) of less than 0.1% at 1 MHz. This makes it ideal for amplifying high-quality video signals.
  • High slew rate: The AD828ARZ-REEL7 has a slew rate of 100 V/µs. This makes it ideal for amplifying fast-changing video signals.

The AD828ARZ-REEL7 is a versatile video amplifier that is ideal for a wide range of applications. It is a good choice for applications where high speed, low power, and wide operating temperature range are important.

Here are some examples of how the AD828ARZ-REEL7 can be used:

  • In a video distribution system, the AD828ARZ-REEL7 can be used to amplify the video signal so that it can be distributed to multiple monitors or projectors.
  • In a video processing system, the AD828ARZ-REEL7 can be used to amplify the video signal before it is processed by the video processor.
  • In a video camera, the AD828ARZ-REEL7 can be used to amplify the video signal from the image sensor.
  • In a video monitor, the AD828ARZ-REEL7 can be used to amplify the video signal before it is displayed on the screen.
  • In a video projector, the AD828ARZ-REEL7 can be used to amplify the video signal before it is projected onto the screen.
  • In a medical imaging system, the AD828ARZ-REEL7 can be used to amplify the video signal from the imaging sensor.
  • In an industrial inspection system, the AD828ARZ-REEL7 can be used to amplify the video signal from the camera before it is processed by the inspection system.

The AD828ARZ-REEL7 is a powerful and versatile video amplifier that is ideal for a wide range of applications.
