AD8231ACPZ-R7

Part No AD8231ACPZ-R7
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP INSTR 7MHZ RRO 16LFCSP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Amplifier Type Instrumentation
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 1.1 V/μs
Gain Bandwidth Product (GBP) 7MHz
Current - Input Bias 250pA
Voltage - Input Offset 4μV
Operating Supply Current 4mA
Channel Output Current 70mA
Supply Voltage - Operating 3 V to 5 V, ±1.5 V to 2.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 16-LFCSP-WQ (4x4)
Win Source Part Number 008394-AD8231ACPZ-R7
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Signal Processing, Sensing & Instrumentation, Industrial, Automation & Process Control, Test & Measurement, Automotive
Ultra Librarian 3D Model Ultra Librarian AD8231ACPZ-R7 CAD Model

Description

AD8231ACPZ-R7: Precision Instrumentation Amplifier by Analog Devices Inc.

The AD8231ACPZ-R7 is a high-performance instrumentation amplifier designed and manufactured by Analog Devices Inc., a leader in precision signal processing technology. This advanced amplifier is tailored for a wide range of applications, including medical instrumentation, industrial process controls, and precision data acquisition systems, where accuracy and stability are paramount.

With its low offset voltage, low noise, and low temperature drift, the AD8231ACPZ-R7 ensures a high degree of precision in measurement tasks. It operates within a supply voltage range of 1.8 V to 5.5 V, making it suitable for both battery-powered devices and standard industrial voltages, providing design flexibility for engineers.

The device features a programmable gain array, allowing users to select gain settings from 1 to 128 in binary steps, which can be easily configured via digital logic inputs. This flexibility in gain adjustment makes the AD8231ACPZ-R7 an ideal choice for applications requiring dynamic range adjustments without the need for external components or complex circuitry.

One of the standout features of the AD8231ACPZ-R7 is its low power consumption, drawing a maximum quiescent current of only 350 µA. This characteristic is especially beneficial for portable and remote sensing applications where power efficiency is crucial. Moreover, the amplifier comes in a compact LFCSP (Lead Frame Chip Scale Package) that is both space-saving and conducive to high-density circuit designs.

The AD8231ACPZ-R7 also includes a reference pin to set an arbitrary output voltage, further enhancing its versatility. Additionally, the amplifier's rail-to-rail output stage ensures maximum dynamic range, which is especially useful when interfacing with analog-to-digital converters (ADCs).

For engineers looking for reliability and precision, the AD8231ACPZ-R7 from Analog Devices Inc. is a top-tier choice that promises to deliver superior performance in a wide array of instrumentation and measurement applications.

Key Features:

  • Low offset voltage
  • Low noise and low temperature drift
  • Programmable gain from 1 to 128
  • Low power consumption: 350 µA max quiescent current
  • Wide supply voltage range: 1.8 V to 5.5 V
  • Compact LFCSP package
  • Rail-to-rail output
  • Reference pin for output voltage setting
