Product Overview: AD7986BCPZ by Analog Devices Inc.

The AD7986BCPZ is a high-precision, 18-bit, PulSAR® Analog-to-Digital Converter (ADC) designed and manufactured by Analog Devices Inc., a leader in high-performance analog, mixed-signal, and digital signal processing integrated circuits. This ADC offers a unique combination of features that make it ideal for high-resolution measurement applications in medical imaging, instrumentation, and automated test equipment.

Key Features and Benefits

• High Resolution: With its 18-bit resolution, the AD7986BCPZ delivers exceptional accuracy and fine detail, making it suitable for applications where precise data acquisition is critical.
• Fast Sampling Rate: The device boasts a fast sampling rate of up to 2 MSPS (Mega-Samples Per Second), allowing for rapid data acquisition without sacrificing precision.
• Low Power Consumption: It is designed for power-sensitive applications, with a typical operating current of only 7 mA at the maximum sampling rate, which can be reduced to 140 µA in standby mode.
• Wide Input Range: The ADC supports a versatile input voltage range, accommodating a variety of signal sources.
• Easy Integration: The compact 10-lead LFCSP (Lead Frame Chip Scale Package) makes it easy to integrate the AD7986BCPZ into a wide range of systems, saving space and simplifying PCB design.
• Robust Interface: Featuring a serial peripheral interface (SPI) that supports various modes, the device ensures reliable and flexible communication with microcontrollers and digital systems.

Applications

• Medical Imaging Systems
• Precision Data Acquisition
• Instrumentation
• Automated Test Equipment
• High-Speed Data Systems

The AD7986BCPZ from Analog Devices Inc. is a testament to the company's commitment to providing high-quality components that enhance the performance and efficiency of electronic systems. Whether it's for intricate medical devices or sophisticated industrial equipment, this ADC is engineered to meet the demands of today's most challenging applications.

Ordering Information

The product is available in a compact package with the part number AD7986BCPZ. For detailed specifications, application support, and ordering information, please visit the Analog Devices Inc. website or contact an authorized distributor.
