AD5689RTCPZ-EP-RL7 Analog Devices Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

AD5689RTCPZ-EP-RL7

Part No AD5689RTCPZ-EP-RL7
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - Digital to Analog Converters (DAC)
Description IC DAC 16BIT V-OUT 16LFCSP
Datasheet
AD5689RTCPZ-EP-RL7 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Bits 16
Number of D/A Converters 2
Settling Time 8µs
Output Type Voltage - Buffered
Differential Output No
Data Interface SPI
Reference Type External, Internal
Voltage - Supply, Analog 2.7V ~ 5.5V
Voltage - Supply, Digital 1.8V ~ 5.5V
INL/DNL (LSB) ±1, ±1 (Max)
Architecture String DAC
Temperature Range - Operating -55°C ~ 125°C
Case / Package 16-WFQFN Exposed Pad, CSP
Supplier Device Package 16-LFCSP (3x3)
Mounting Type Surface Mount
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1496927-AD5689RTCPZ-EP-RL7
Ultra Librarian 3D Model Ultra Librarian AD5689RTCPZ-EP-RL7 CAD Model

Description

N
