AD5252BRUZ1-RL7 Digital Potentiometer

The AD5252BRUZ1-RL7 is a precision digital potentiometer manufactured by Analog Devices Inc., one of the leading companies in high-performance analog, mixed-signal, and digital signal processing integrated circuits. This product offers a reliable and flexible solution for applications requiring digitally controlled resistance settings.

Key Features

• Resolution: The AD5252BRUZ1-RL7 features a dual-channel, 256-position resolution, providing fine adjustment capability for various application requirements.
• Interface: It incorporates an I²C-compatible serial interface, which allows easy integration into a wide range of systems and ensures compatibility with most microcontrollers and digital systems.
• Memory: This digital potentiometer includes nonvolatile memory (EEPROM) to store the resistance settings, ensuring that the last programmed setting is retained even after power cycling.
• Power Supply: It operates on a wide single-supply voltage range from 2.7V to 5.5V, making it suitable for both 3V and 5V systems.
• Package: The device is offered in a compact TSSOP (thin shrink small outline package) form, which is ideal for space-constrained applications.
• Temperature Range: It is designed to operate over an extended industrial temperature range of -40°C to +105°C, ensuring reliable performance in harsh environments.

Applications

The AD5252BRUZ1-RL7 is versatile and can be used in a variety of applications, including:

• Automated calibration systems
• Programmable filters and delays
• Adjustable power supplies and voltage dividers
• Audio/visual equipment

Quality and Reliability

As with all Analog Devices products, the AD5252BRUZ1-RL7 is built to meet high standards of quality and reliability. Users can expect consistent performance and durability from this digital potentiometer, making it an excellent choice for both prototyping and mass production.

Whether you are designing consumer electronics, industrial control systems, or automotive applications, the AD5252BRUZ1-RL7 from Analog Devices Inc. offers a compact, precise, and reliable solution for digital resistance trimming and adjustment needs.
