The AD5160BRJZ10-R2 is a high-performance digital potentiometer brought to you by Analog Devices Inc., a leader in the field of precision high-performance electronics. This compact digital potentiometer offers a unique combination of versatility and efficiency, making it an ideal choice for a wide range of applications including calibration adjustments, programmable filters, and signal conditioning.

Key Features

• Compact Size: The AD5160 comes in a small SOT-23 8-lead package, allowing for easy integration into space-constrained applications.
• Resolution: It features a 256-position resolution, providing fine adjustment capability.
• Single Supply Operation: Operates from a single 2.7 V to 5.5 V supply, making it suitable for use in both 3 V and 5 V systems.
• Endurance: It boasts a high endurance of 200,000 wiper switch cycles, ensuring a long operational life.
• Temperature Range: The device operates over an extended industrial temperature range of -40°C to +125°C.

Applications

The AD5160BRJZ10-R2 is highly adaptable and can be used in various applications such as:

• Adjustable power supplies
• LCD screen calibration
• Automotive electronics
• Portable battery-powered devices
• Audio/visual equipment

Technical Specifications

With its robust design and reliable performance, the AD5160BRJZ10-R2 from Analog Devices Inc. stands out as a top-tier solution for precision digital potentiometer requirements. Its user-friendly interface and durable construction ensure that it will remain a staple in electronic designs for years to come.
