AD2S80AAD

Part No AD2S80AAD
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - ADCs/DACs - Special Purpose
Description Variable Resolution, Monolithic Resolver-to-Digital Converter
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Analog Devices Inc.
Packaging Tube
Type R/D Converter
Resolution (Bits) 10, 12, 14, 16 b
Data Interface Parallel
Operating Supply Voltage ±10.8 V ~ 13.2 V
Operating Temperature Range -40°C ~ 85°C
Mounting Style Through Hole
Package 40-CDIP (0.600", 15.24mm)
Manufacturer Package 40-CDIP
RoHS State Request Verification
Win Source Part Number 1135797-AD2S80AAD
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Limited
Family Name AD2S80
Introduction Date October 31, 1995
ECCN EAR99
Country of Origin Philippines
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian AD2S80AAD CAD Model

Description

Product Overview: AD2S80AAD from Analog Devices Inc.

The AD2S80AAD is a high-performance resolver-to-digital converter manufactured by Analog Devices Inc., a leader in the semiconductor industry. This precision product is designed to convert resolver format input signals into digital data with exceptional accuracy and reliability. The AD2S80AAD is particularly suitable for applications in industrial systems, robotics, and aerospace where precise position sensing and motion control are critical.

Key Features

  • High Resolution: The AD2S80AAD offers a resolution of up to 16 bits, ensuring fine granularity in position measurement.
  • Variable Tracking Rate: It features a tracking rate that can be adjusted to match the dynamics of the application, providing flexibility across different use cases.
  • Loss of Signal Detection: The device includes a built-in loss of signal circuitry that alerts the system in the event of a signal interruption, enhancing the safety and robustness of the application.
  • Digital Self-Test: With an integrated self-test capability, the AD2S80AAD can perform diagnostics to verify its operational integrity, ensuring reliable performance.

Applications

  • Industrial Automation
  • Servo Motor Control
  • Robotics
  • Aerospace and Defense Systems
  • Antenna Positioning Systems

Performance and Reliability

The AD2S80AAD is designed to operate within a temperature range of -55°C to +125°C, making it suitable for harsh environments. Its robust construction and high-quality manufacturing standards ensure that it delivers consistent performance over a long service life. Analog Devices Inc. has a reputation for producing reliable components that meet the stringent requirements of industrial and aerospace applications, and the AD2S80AAD is no exception.

Integrating the AD2S80AAD into your system will provide precise angular displacement and velocity measurements, which are essential for high-performance control systems. Whether you are designing a new system or upgrading an existing one, the AD2S80AAD from Analog Devices Inc. is an excellent choice for achieving superior resolver-to-digital conversion.
