Product Overview: AD1584ARTZ-REEL7

The AD1584ARTZ-REEL7 is a high-precision, low-power voltage reference component from Analog Devices Inc., an industry leader in the design and manufacturing of high-performance integrated circuits. This device is part of the AD1584 series, which offers a series of bandgap voltage references that provide a fixed 4.096V output from an input voltage range of 4.2V to 18V. The AD1584ARTZ-REEL7 comes in a compact SOT-23 package, making it suitable for space-constrained applications.

Key Features

• Precision Voltage Reference: The AD1584 provides a 4.096V output, which is ideal for analog-to-digital converters (ADCs) with 12-bit resolution, ensuring accurate reference voltage for precise conversions.
• Low Power Consumption: With a quiescent current of only 60 µA (typical), the AD1584 is optimized for battery-powered and portable devices, where power efficiency is critical.
• Wide Input Voltage Range: The device operates over a broad input voltage range from 4.2V to 18V, offering design flexibility for various power supply configurations.
• High Output Current: Capable of sourcing up to 5 mA and sinking up to 1 mA, the AD1584 can drive heavy loads, making it versatile for diverse applications.
• Low Temperature Coefficient: The AD1584 features a low temperature coefficient of 10 ppm/°C (max), ensuring stable performance across a wide temperature range from -40°C to +125°C.
• Excellent Load Regulation: The load regulation specification of 25 ppm/mA helps maintain output voltage stability under varying load conditions.
• Compact Packaging: The small SOT-23 package is space-efficient, which is essential for compact PCB layouts and high-density electronic assemblies.

Applications

The AD1584ARTZ-REEL7 is suitable for a broad range of applications that require a stable and precise voltage reference. It is commonly used in:

• Data acquisition systems
• Portable instrumentation
• Battery-powered devices
• Precision voltage regulators
• Analog-to-digital converters (ADCs)
• Digital-to-analog converters (DACs)
• Industrial control systems

With its combination of precision, low power consumption, and compact form factor, the AD1584ARTZ-REEL7 from Analog Devices Inc. is an ideal choice for designers looking to enhance the accuracy and efficiency of their electronic systems.
