75869-101 Real Image
Same model may have multiple batches, images only for reference.

75869-101

Part No 75869-101
Manufacturer Amphenol
Catalog Rectangular Connectors
Description CONN HEADER VERT 10POS 2.54MM / Connector Header Through Hole 10 position 0.100" (2.54mm)
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors>Headers, Male Pins
Manufacturer Amphenol ICC (FCI)
Packaging Tube
Product Status Obsolete
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 10
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.236" (6.00mm)
Contact Length - Post 0.120" (3.05mm)
Insulation Height 0.377" (9.57mm)
Contact Shape Square
Contact Finish - Mating Gold, GXT™
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Material Phosphor Bronze
Insulation Material Thermoplastic, Glass Filled
Features Keying Slot
Material Flammability Rating UL94 V-0
Insulation Color Blue
Base Product Number 75869
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Standard Package 29
Win Source Part Number 1333071-75869-101
Ultra Librarian 3D Model Ultra Librarian 75869-101 CAD Model

Description

This male pin header connector from Amphenol ICC (FCI) 1333071-10114619-G10LF is a through-hole mounting connector that is made of thermoplastic and glass-filled insulation material.

  • Connection Style: Board-to-Cable/Wire
  • Pitch-Mating: 0.100 inches (2.54mm)
  • Positions: 10
  • Rows: Two
  • Positions Loaded: All
  • Shrouded: 4-Wall
  • Contact Shape: Square
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Contact Material: Phosphor Bronze
  • Contact Finish-Mating: Gold GXT
  • Insulation Color: Blue
  • Insulation Height: 0.377 inches (9.57mm)
  • Material Flammability Rating: UL94 V-0
  • Packaging: Tube
  • Standard Package: 29 pieces
