The Amphenol ICC (FCI) 1332438-67997-272HLF is a male pin header connector that is perfect for use in a range of applications.

• Manufacturer: Amphenol ICC (FCI)
• Positions: 72
• Packaging: Bulk
• Rows: Two
• Connector Type: Header
• Contact Type: Male Pin
• Positions Loaded: All
• Termination: Solder
• Fastening Type: Push-Pull
• Contact Material: Phosphor Bronze
• Mounting Style: Through Hole
• Style: Board to Board
• Pitch-Mating: 0.100" (2.54mm)
• Contact Finish-Mating: Gold or Gold, GXT™
• Contact Finish Thickness-Mating: 15.0µin (0.38µm)
• Insulation Color: Black
• Shrouding: Unshrouded
• Row Spacing-Mating: 0.100" (2.54mm)
• Contact Length-Post: 0.120" (3.05mm)
• Overall Contact Length: 0.450" (11.43mm)
• Insulation Height: 0.100" (2.54mm)
• Contact Shape: Square
• Temperature Range-Operating: -65°C ~ 130°C
• Contact Length-Mating: 0.230" (5.84mm)
• RoHS Compliant: Yes
• Current Rating: 3A
