Same model may have multiple batches, images only for reference.
TSM-150-03-S-DV Real Image
Same model may have multiple batches, images only for reference.

TSM-150-03-S-DV

Part No TSM-150-03-S-DV
Manufacturer Samtec Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 100POS 2.54MM / Connector Header Surface Mount 100 position 0.100" (2.54mm)
Datasheet
TSM-150-03-S-DV Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Samtec Inc.
Series TSM
Package Tube
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 100
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.420" (10.67mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Liquid Crystal Polymer (LCP)
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Base Product Number TSM-150
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Standard Package 1
Win Source Part Number 981965-TSM-150-03-S-DV
Ultra Librarian 3D Model Ultra Librarian TSM-150-03-S-DV CAD Model

Description

981965-TSM-150-03-S-DV is a board-to-board or cable connector from Samtec Inc.

  • Connector Type: Header
  • Pin Type: Male
  • Number of Positions: 100
  • Number of Rows: Two
  • Pitch: 0.100" (2.54mm)
  • Contact Finish: Gold
  • Contact Finish Thickness: 30.0µin (0.76µm)
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Flammability Rating: UL94 V-0
  • Termination Type: Solder
  • Fastening Type: Push-Pull
  • Operating Temperature Range: -55°C to 125°C
  • ECCN: EAR99
  • MSL Level: Unlimited
  • HTSUS: 8536.69.4040
