Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - System On Chip (SoC)
Mfr AMD
Series Zynq®-7000
Package Tray
Product Status Active
Architecture MCU, FPGA
Core Processor Dual ARM® Cortex®-A9 MPCore™ with CoreSight™
RAM Size 256KB
Peripherals DMA
Connectivity CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
Speed 1GHz
Primary Attributes Kintex™-7 FPGA, 350K Logic Cells
Temperature Range - Operating 0°C ~ 100°C (TJ)
Package / Case 900-BBGA, FCBGA
Supplier Device Package 900-FCBGA (31x31)
Number of I/O 130
Base Product Number XC7Z045
Standard Package 1 pcs
MSL Level 4 (72 Hours)
REACH Status REACH Unaffected
ECCN 3A001A7B
HTSUS 8542.39.0001
Win Source Part Number 846704-XC7Z045-3FFG900E
Ultra Librarian 3D Model Ultra Librarian XC7Z045-3FFG900E CAD Model

Description

The XC7Z045-3FFG900E is a System on Chip (SoC) FPGA from the Zynq-7000 series.

  • Processor: dual ARM Cortex-A9 MPCore processor with CoreSight technology
  • Processor Speed: 1GHz
  • Package: Tray
  • Standard Package: 1
  • Connectivity: CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, and USB OTG
  • Peripheral: DMA
  • I/Os: 130
  • RAM Size: 256KB
  • Flash Size: Not Specified
  • Architecture: MCU and FPGA
  • FPGA: Kintex-7
  • Logic Cells: 350K
  • Operating Temperature: 0°C to 100°C
  • Mounting Type: Surface Mount
