AO3400

Name: AO3400
Brand: Alpha & Omega Semiconductor Inc.
SKU: 562055
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	AO3400
Manufacturer	Alpha & Omega Semiconductor Inc.
Catalog	FETs - Single
Description	Trans MOSFET N-CH 30V 5.8A 3-Pin SOT-23 / N-Channel Enhancement Mode Field Effect Transistor \| MOSFET N-CH 30V 5.8A SOT23-3
Datasheet	AO3400 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Alpha & Omega Semiconductor Inc.
Packaging	Tape and Reel
Part Status	Preliminary
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	30V
Id - Continuous Drain Current	5.8A
Drive Voltage (Max Rds On, Min Rds On)	2.5V, 10V
Rds On (Maximum) at Id, Vgs	28mOhm at 5.8A, 10V
Gate Source Voltage(th) (Maximum) at Id	1.45V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	7nC at 4.5V
Gate Source Voltage (Maximum)	±12V
Input Capacitance (Ciss) (Maximum) at Vds	630pF at 15V
Power Dissipation (Maximum)	1.4W
Temperature Range - Operating	-55°C ~ 150°C
Mounting Style	SMD
Supplier Device Package	SOT-23-3
Manufacturer Package	TO-236-3, SC-59, SOT-23-3
Manufacturer Pack Quantity	3,000
MSL Level	1 (Unlimited)
Win Source Part Number	1144743-AO3400
Manufacturer Homepage	www.aosmd.com
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	AO3400
Introduction Date	May 06, 2008
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian AO3400 CAD Model

Alternative Products

Description

The AO3400 is a MOSFET transistor manufactured by Alpha & Omega Semiconductor Inc.

Part Status: Preliminary
Transistor Polarity: N-Channel
Drain-Source Breakdown Voltage: 30V
Continuous Drain Current: 5.8A
Rds On: 28mOhm @ 5.8A and 10V
Gate-Source Voltage(th): 1.45V @ 250μA
Package: SOT-23-3
Power Dissipation: 1.4W
Gate-Source Voltage: ±12V
Input Capacitance (Ciss): 630pF @ 15V
Halogen-Free Compliant: Yes
Popularity: High
Supply and Demand Status: Sufficient
Manufacturer Pack Quantity: 3,000
Estimated EOL Date: 2022
