ACS758ECB-200U-PFF-T Real Image ACS758ECB-200U-PFF-T real image17074 ACS758ECB-200U-PFF-T Real Image
Same model may have multiple batches, images only for reference.
ACS758ECB-200U-PFF-T Real Image ACS758ECB-200U-PFF-T real image17074 ACS758ECB-200U-PFF-T Real Image
ACS758ECB-200U-PFF-T Real Image ACS758ECB-200U-PFF-T real image17074 ACS758ECB-200U-PFF-T Real Image
Same model may have multiple batches, images only for reference.

ACS758ECB-200U-PFF-T

Part No ACS758ECB-200U-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description The Allegro ACS758 family of current sensor ICs provides economical and precise solutions for AC or DC current sensing.
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Series Automotive, AEC-Q100
Packaging Tube
For Measuring DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 200A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 20mV/A
Frequency DC ~ 120kHz
Linearity ±1%
Accuracy ±1.2%
Operating Supply Voltage 3 V ~ 5.5 V
Response Time 4μs
Maximum Supply Current 13.5mA
Operating Temperature Range -40°C ~ 85°C
Polarization Unidirectional
Mounting Style Through Hole
Package 5-CB Formed Leads, PFF
Win Source Part Number 1135519-ACS758ECB-200U-PFF-T
Manufacturer Homepage www.allegromicro.com
Popularity Medium
Supply and Demand Status Limited
Quantity per package 34
Family Name ACS758ECB
Introduction Date March 26, 2009
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian ACS758ECB-200U-PFF-T CAD Model

Description

The ACS758ECB-200U-PFF-T is a current sensor manufactured by Allegro MicroSystems, LLC.

  • Category: Sensors, Transducers
  • Packaging: Tube
  • Sensitivity: 20mV/A
  • Sensing Method: Hall Effect, Open Loop
  • Operating Temperature Range: -40°C ~ 85°C
  • Output: Ratiometric, voltage
