ACS756SCA-050B-PFF-T Real Image ACS756SCA-050B-PFF-T real image
Same model may have multiple batches, images only for reference.
ACS756SCA-050B-PFF-T Real Image ACS756SCA-050B-PFF-T real image
ACS756SCA-050B-PFF-T Real Image ACS756SCA-050B-PFF-T real image
Same model may have multiple batches, images only for reference.

ACS756SCA-050B-PFF-T

Part No ACS756SCA-050B-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 50A AC/DC
Datasheet
ACS756SCA-050B-PFF-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Tube/Rail
Status Obsolete(EOL)
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 50A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 40mV/A
Frequency DC to 120kHz
Linearity ±1%
Accuracy ±5%
Supply Voltage - Operating 3 V to 5.5 V
Response Time 3μs
Current - Supply (Max) 14mA
Temperature Range - Operating -20°C to 85°C
Polarization Bidirectional
Mounting Through Hole
Dimension 5-CA Formed Leads
Win Source Part Number 086994-ACS756SCA-050B-PFF-T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 34
Ultra Librarian 3D Model Ultra Librarian ACS756SCA-050B-PFF-T CAD Model

Description

Product Overview

The ACS756SCA-050B-PFF-T offers a reliable and precise solution for high-current sensing applications. Allegro MicroSystems has engineered this sensor for durability and accuracy in performance-critical settings.

Features and Benefits

  • High Overcurrent Protection: Prevents damage from unexpected surges.
  • Fast Response Time: Ideal for dynamic control systems.
  • Durable Construction: Ensures long service life.
  • Integrated Signal Amplification: Enhances measurement fidelity.

Applications

  • Industrial Motor Drives
  • Electric Vehicle Systems
  • Uninterruptible Power Supplies (UPS)

The ACS756SCA-050B-PFF-T stands as a superior choice for developers needing performance and longevity in their electrical sensing components.
