Same model may have multiple batches, images only for reference.

ACS722LLCTR-10AU-T

Name: ACS722LLCTR-10AU-T
Brand: Allegro MicroSystems, LLC
SKU: 766982
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	ACS722LLCTR-10AU-T
Manufacturer	Allegro MicroSystems, LLC
Catalog	Current Transducers
Description	SENSOR CURRENT HALL 10A DC
Datasheet	ACS722LLCTR-10AU-T Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Sensors, Transducers
Manufacturer	Allegro MicroSystems, LLC
Packaging	Reel package
For Measuring	DC
Sensor Type	Hall Effect, Open Loop
Current - Sensing	10A
Number of Channels	1
Output	Ratiometric, Voltage
Sensitivity	264mV/A
Frequency	DC ~ 80kHz
Linearity	±1%
Accuracy	±3%
Operating Supply Voltage	3 V ~ 3.6 V
Response Time	5μs
Maximum Supply Current	12mA
Operating Temperature Range	-40°C ~ 150°C
Polarization	Unidirectional
Mounting	SMD
Package	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	766982-ACS722LLCTR-10AU-T
Popularity	Medium
Supply and Demand Status	Balance
Family Name	ACS722
Introduction Date	June 11, 2014
ECCN	EAR99
Country of Origin	Philippines
Estimated EOL Date	2025
Ultra Librarian 3D Model	Ultra Librarian ACS722LLCTR-10AU-T CAD Model

Alternative Products

Description

The ACS722LLCTR-10AU-T is a Hall Effect, Open Loop current sensor from Allegro MicroSystems.

Polarization: Unidirectional
Sensitivity: 264mV/A
DC Current: 10A
Output: Ratiometric, voltage
Linearity: ±1%
Accuracy: ±3%
Response Time: 5μs
Frequency Range: DC to 80kHz
Mounting: SMD
Package: 8-SOIC (0.154 inches)
Operating Temperature: -40°C to 150°C
Maximum Supply Current: 12mA
