ACS713ELCTR-30A-T Allegro MicroSystems, LLC ACS713ELCTR-30A-T Real Image1 ACS713ELCTR-30A-T Real Image2 ACS713ELCTR-30A-T Real Image3 ACS713ELCTR-30A-T Real Image4 ACS713ELCTR-30A-T Real Image5 ACS713ELCTR-30A-T Real Image6
Same model may have multiple batches, images only for reference.
ACS713ELCTR-30A-T Allegro MicroSystems, LLC ACS713ELCTR-30A-T Real Image1 ACS713ELCTR-30A-T Real Image2 ACS713ELCTR-30A-T Real Image3 ACS713ELCTR-30A-T Real Image4 ACS713ELCTR-30A-T Real Image5 ACS713ELCTR-30A-T Real Image6
ACS713ELCTR-30A-T Allegro MicroSystems, LLC ACS713ELCTR-30A-T Real Image1 ACS713ELCTR-30A-T Real Image2 ACS713ELCTR-30A-T Real Image3 ACS713ELCTR-30A-T Real Image4 ACS713ELCTR-30A-T Real Image5 ACS713ELCTR-30A-T Real Image6
Same model may have multiple batches, images only for reference.

ACS713ELCTR-30A-T

Part No ACS713ELCTR-30A-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 30A DC
Datasheet
ACS713ELCTR-30A-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel - TR
Status Active
For Measuring DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 30A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 133mV/A
Frequency DC to 80kHz
Linearity ±1.5%
Accuracy ±1.5%
Supply Voltage - Operating 5V
Response Time 5μs
Current - Supply (Max) 13mA
Temperature Range - Operating -40°C to 85°C
Polarization Unidirectional
Mounting SMD (SMT)
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 007891-ACS713ELCTR-30A-T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Sensing & Instrumentation, Industrial, Commercial, Communications & Networking, Motor Drive & Control, Power Management, Safety
Family Name ACS713
Introduction Date December 18, 2006
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2019
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian ACS713ELCTR-30A-T CAD Model

Description

ACS713ELCTR-30A-T Current Sensor

Designed for applications requiring higher current capacity, the ACS713ELCTR-30A-T current sensor offers enhanced current measurement capabilities up to 30A. This sensor integrates seamlessly into an array of electronic systems.

  • Applications:
    • Renewable energy systems
    • Smart grid solutions
    • Electric vehicle charging stations
    • Home appliance monitoring
  • Features and Benefits:
    • Robust measurement range
    • Offer superior isolation characteristics
    • User-friendly integration and calibration
    • Long lifecycle for industrial use

The ACS713ELCTR-30A-T is engineered to withstand challenging environments and provides consistent performance, thus ensuring efficient energy management and system reliability.
