ACS709LLFTR-35BB-T Real Image ACS709LLFTR-35BB-T real image15012 ACS709LLFTR-35BB-T Real Image
Same model may have multiple batches, images only for reference.
ACS709LLFTR-35BB-T Real Image ACS709LLFTR-35BB-T real image15012 ACS709LLFTR-35BB-T Real Image
ACS709LLFTR-35BB-T Real Image ACS709LLFTR-35BB-T real image15012 ACS709LLFTR-35BB-T Real Image
Same model may have multiple batches, images only for reference.

ACS709LLFTR-35BB-T

Part No ACS709LLFTR-35BB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 37.5A AC/DC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel - TR
Status Active
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 37.5A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 28mV/A
Frequency DC to 120kHz
Linearity ±0.25%
Accuracy ±3%
Supply Voltage - Operating 3 V to 5.5 V
Response Time 4μs
Current - Supply (Max) 14.5mA
Temperature Range - Operating -40°C to 150°C
Polarization Bidirectional
Mounting SMD (SMT)
Dimension 24-SSOP (0.154", 3.90mm Width)
Win Source Part Number 1011840-ACS709LLFTR-35BB-T
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial, Commercial, Automotive, Communications & Networking
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian ACS709LLFTR-35BB-T CAD Model

Description

The ACS709LLFTR-35BB-T is an open loop Hall Effect sensor manufactured by Allegro MicroSystems, LLC.

  • Polarization: Bidirectional
  • Output: Ratiometric voltage
  • Sensitivity: 28mV/A
  • Sensing Current: Up to 37.5A
  • Response Time: 4μs
  • Frequency: DC to 120kHz
  • Applications: Industrial, commercial, automotive, communications and networking
  • Linearity: ±0.25%
  • Accuracy: ±3%
  • Operating Temperature: -40°C to 150°C
  • Operating Voltage: 3V to 5.5V
  • Packaging: Reel
  • Quantity per Package: 2,500
