ALFT-04-9 Abracon LLC – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ALFT-04-9

Part No ALFT-04-9
Manufacturer Abracon LLC
Catalog Common Mode Chokes
Description CMC 10MH 3A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Last Time Buy
Filter Type Signal Line
Number of Lines 2
Inductance @ Frequency 10 mH @ 1 kHz
Current Rating (Max) 3A
DC Resistance (DCR) (Max) 40mOhm
Temperature Range - Operating -25°C ~ 85°C
Mounting Type Through Hole
Size / Dimension 1.339" L x 0.709" W (34.00mm x 18.00mm)
Height (Max) 1.251" (31.80mm)
Case / Package Vertical, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1530341-ALFT-04-9
Ultra Librarian 3D Model Ultra Librarian ALFT-04-9 CAD Model
