Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Uncategorized
Manufacturer 3Peak
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 840802-TP1941-TR
Ultra Librarian 3D Model Ultra Librarian TP1941-TR CAD Model

Description

The TP1941-TR is a transistor from 3Peak that is categorized as an uncategorized product.

  • Supply and Demand Status: balanced
  • Applications: power supplies, motor control, and inverters
  • Description: It is a reliable and durable transistor that can withstand harsh environments and extreme temperatures.
  • Maximum Power Dissipation: 480W
  • Drain-to-Source Breakdown Voltage (Vds): 200V
  • Continuous Drain Current (Id): 86A
  • Rds On (Maximum) @ Id, Vgs: 29mOhm @ 500mA, 10V
  • Gate-Source Voltage(th) (Maximum) @ Id: 5V @ 1mA
  • Gate Charge (Qg) (Maximum) @ Vgs: 90nC @ 10V
  • Gate-Source Voltage (Vgs) (Max): ±30V
  • Input Capacitance (Ciss) (Maximum) @ Vds: 4500pF @ 25V
