Z8S18020VSG Real Image Z8S18020VSG Real Image1 Z8S18020VSG Real Image2 Z8S18020VSG Real Image3
Same model may have multiple batches, images only for reference.
Z8S18020VSG Real Image Z8S18020VSG Real Image1 Z8S18020VSG Real Image2 Z8S18020VSG Real Image3
Z8S18020VSG Real Image Z8S18020VSG Real Image1 Z8S18020VSG Real Image2 Z8S18020VSG Real Image3
Same model may have multiple batches, images only for reference.

Z8S18020VSG

Part No Z8S18020VSG
Manufacturer Zilog
Catalog Embedded - Microprocessors
Description IC MPU Z180 20MHZ 68PLCC
Datasheet
Z8S18020VSG Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Zilog
Packaging Tube/Rail
Status Active
Core Processor Z8S180
Number of Cores/Bus Width 1 Core, 8-Bit
Speed(Frequency) 20MHz
RAM Controllers DRAM
Graphics Acceleration No
Voltage - I/O 5.0V
Temperature Range - Operating 0°C to 70°C (TA)
Security Package / Case 68-LCC (J-Lead)
Case / Package 68-PLCC
Additional Interfaces ASCI, CSIO, UART
Win Source Part Number 057948-Z8S18020VSG
Popularity Medium
Supply and Demand Status Limited
Quantity per package 20
Ultra Librarian 3D Model Ultra Librarian Z8S18020VSG CAD Model

Description

The Z8S18020VSG is an 8-bit microcontroller from Zilog.

  • Core Processor: Z8S180
  • Cores: 1
  • Bus Width: 8-bit
  • RAM Controllers: DRAM
  • Additional Interfaces: ASCI, CSIO, and UART
  • Package: 68-PLCC
  • Popularity: medium
  • Supply and Demand Status: limited
  • Quantity per Package: 20
