SDT23C712L02

Name: SDT23C712L02
Brand: Yageo
SKU: 317909
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SDT23C712L02
Manufacturer	Yageo
Catalog	TVS - Diodes
Description	TVS DIODE 12VWM 20VC SOT23
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	YAGEO
Series	SDT23C712L02
Package	Tape & Reel
Product Status	Active
Type	Zener
Bidirectional Channels	2
Voltage - Reverse Standoff (Typ)	12V (Max)
Voltage - Breakdown (Min)	13.3V
Voltage - Clamping (Max) @ Ipp	20V
Current - Peak Pulse (10/1000µs)	5A (8/20µs)
Power - Peak Pulse	400W
Power Line Protection	No
Applications	General Purpose
Capacitance @ Frequency	75pF @ 1MHz (Max)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Supplier Device Package	SOT-23
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	317909-SDT23C712L02
Ultra Librarian 3D Model	Ultra Librarian SDT23C712L02 CAD Model

Description

The 317909-SDT23C712L02 is a zener TVS diode from YAGEO's SDT23C712L02 series. It is designed for general-purpose power line protection against transient voltage events.

Reverse Standoff Voltage: 12V
Breakdown Voltage: 13.3V
Clamping Voltage: 20V @ peak pulse power of 400W
Diode Type: Bidirectional
Channels: Two
Capacitance: 75pF @ 1MHz
Mounting Type: Surface Mountable
Package: TO-236-3 (SC-59, SOT-23-3)
Operating Temperature: -55°C to 150°C
