7016X1/5

Name: 7016X1/5
Brand: Visual Communications Company - VCC
SKU: 1129654
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	7016X1/5
Manufacturer	Visual Communications Company - VCC
Catalog	LED Indication - Discrete
Description	LED GREEN/RED CLEAR SMD / Green, Red LED Indication - Discrete 2.2V Green, 1.75V Red 4-SMD, No Lead
Datasheet	7016X1/5 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Optoelectronics>LED Indication - Discrete
Mfr	Visual Communications Company - VCC
Series	7016X
Package	Tape & Reel
Color	Green, Red
Configuration	Independent
Lens Color	Colorless
Lens Transparency	Clear
Millicandela Rating	14.5mcd Green, 12.5mcd Red
Lens Style	Rectangle with Flat Top
Lens Size	2.30mm x 2.10mm
Voltage - Forward (Vf) (Typ)	2.2V Green, 1.75V Red
Current - Test	20mA Green, 20mA Red
Viewing Angle	110°
Mounting	SMD (SMT)
Wavelength - Peak	570nm Green, 660nm Red
Package / Case	4-SMD, No Lead
Supplier Device Package	SMD
Dimension	3.00mm L x 2.49mm W
Height (Max)	1.30mm
MSL Level	2 (1 Year)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.41.0000
Other Names	7016X1/5TR,7016X1/5-ND,7016X1/5CT,Q1171121,7016X1/5DKR
Standard Package	2,500
Win Source Part Number	1129654-7016X1/5
Ultra Librarian 3D Model	Ultra Librarian 7016X1/5 CAD Model

Alternative Products

Description

The Visual Communications Company - VCC 1129654-7016X1/5 is a surface-mount LED indication component with two independent configurations for green and red colors.

Viewing Angle: 110°
Millicandela Rating (Green): 14.5mcd
Millicandela Rating (Red): 12.5mcd
Voltage-Forward (Green): 2.2V
Voltage-Forward (Red): 1.75V
Test Current: 20mA (both colors)
Peak Wavelength (Green): 570nm
Peak Wavelength (Red): 660nm
Package: 4-SMD, No Lead
Dimension: 3.00mm L x 2.49mm W
Lens Style: Rectangle with flat top
Lens Size: 2.30mm x 2.10mm
Package Quantity: 2,500
ECCN: EAR99
MSL Level: 2 (1 Year)
REACH: REACH unaffected
HTSUS: 8541.41.0000
