VS-P103W

Part No VS-P103W
Manufacturer Vishay
Catalog SCRs - Single - Modules
Description SCR HY-BRIDGE 800V 25A PACE-PAK / SCR Module Diode 800V 375A 8-Pin Case D-19
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Bulk
Structure Bridge, Single Phase - SCRs/Diodes (Layout 1)
Number of SCRs, Diodes 2 SCRs, 2 Diodes
Voltage - Off State 800V
Current - On State (It (RMS)) (Maximum) 25A (DC)
Voltage - Gate Trigger (Vgt) (Maximum) 2V
Current - Gate Trigger (Igt) (Maximum) 60mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 357A, 375A
Current - Hold (Ih) (Maximum) 130mA
Operating Temperature Range -40°C ~ 125°C (TJ)
Mounting Chassis Mount
Package 8-PACE-PAK
Win Source Part Number 791090-VS-P103W
Popularity Medium
Supply and Demand Status Limited
Family Name VS-P103W
Ultra Librarian 3D Model Ultra Librarian VS-P103W CAD Model

Description

The Vishay Semiconductor Diodes Division VS-P103W is a single-phase bridge structure with 2 SCRs and 2 diodes.

  • Win Source Part Number: 791090-VS-P103W
  • Voltage Off State: 800V
  • Current on State: 25A (DC)
