Same model may have multiple batches, images only for reference.

VBUS054CD-FHI-GS08

Name: VBUS054CD-FHI-GS08
Brand: Vishay
SKU: 397494
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	VBUS054CD-FHI-GS08
Manufacturer	Vishay
Catalog	TVS - Diodes
Description	ESD Suppressor Diode Diode Array Bi-Dir 5V 11-Pin LLP-2513 T/R / TVS DIODE 5VWM 13VC LLP2513
Datasheet	VBUS054CD-FHI-GS08 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Circuit Protection
Manufacturer	Vishay
Packaging	Reel - TR
Status	Obsolete(EOL)
Type	Steering (Rail to Rail)
Unidirectional Channels	4
STAND-OFF Voltage (Vwm)	5V (Max)
Minimum Breakdown Voltage	6.9V
Max Clamping Voltage	13V
Peak Pulse Current(Ippm)	3.5A (8/20μs)
Power Dissipation - Pd	45W
Power Line Protection	Yes
Applications	General Purpose
Capacitance @ Frequency	0.8pF @ 1MHz
Temperature Range - Operating	-40°C to 125°C (TJ)
Mounting	SMD (SMT)
Case / Package	LLP2513-11L
Win Source Part Number	057274-VBUS054CD-FHI-GS08
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	VBUS054CD-FHI
Introduction Date	October 30, 2008
ECCN	EAR99
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian VBUS054CD-FHI-GS08 CAD Model

Alternative Products

Description

The Vishay VBUS054CD-FHI-GS08 is a 4-channel, unidirectional steering circuit protection device designed for general-purpose applications.

Protection: Power line protection
Capacitance: 0.8pF @ 1MHz
Maximum Stand-off Voltage: 5V
Minimum Breakdown Voltage: 6.9V
Peak Pulse Current: 3.5A (8/20μs)
Power Dissipation: 45W
Package: LLP2513-11L
Operating Temperature Range: -40°C to 125°C
Product Status: Discontinued
