VB30200C-E3/8W Vishay VB30200C-E3/8W Real Image VB30200C-E3/8W label picture 2 VB30200C-E3/8W real image
Same model may have multiple batches, images only for reference.
VB30200C-E3/8W Vishay VB30200C-E3/8W Real Image VB30200C-E3/8W label picture 2 VB30200C-E3/8W real image
VB30200C-E3/8W Vishay VB30200C-E3/8W Real Image VB30200C-E3/8W label picture 2 VB30200C-E3/8W real image
Same model may have multiple batches, images only for reference.

VB30200C-E3/8W

Part No VB30200C-E3/8W
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description Rectifier Diode Schottky 200V 30A 3-Pin(2+Tab) TO-263AB T/R / DIODE ARRAY SCHOTTKY 200V TO263
Datasheet
VB30200C-E3/8W Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 200V
Current - Average Rectified (Io) (per Diode) 15A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 15A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 160μA @ 200V
Operating Temperature - Junction -40°C to 150°C
Mounting SMD (SMT)
Case / Package TO-263AB
Win Source Part Number 1116912-VB30200C-E3/8W
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name VB30200C
Introduction Date January 08, 2007
ECCN EAR99
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian VB30200C-E3/8W CAD Model

Description

The Vishay 1116912-VB30200C-E3/8W is a Schottky diode that is part of the VB30200C family of discrete semiconductor products.

  • Manufacturer: Vishay
  • Supply and Demand Status: Balanced
  • Maximum DC Reverse Voltage: 200V
  • Maximum Forward Voltage: 1.1V @ 15A
  • Operating Temperature Range: -40°C to 150°C
