V8P10-M3/86A Vishay V8P10-M3/86A Real Image V8P10-M3/86A real image
Same model may have multiple batches, images only for reference.
V8P10-M3/86A Vishay V8P10-M3/86A Real Image V8P10-M3/86A real image
V8P10-M3/86A Vishay V8P10-M3/86A Real Image V8P10-M3/86A real image
Same model may have multiple batches, images only for reference.

V8P10-M3/86A

Part No V8P10-M3/86A
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 100V 8A TO277A
Datasheet
V8P10-M3/86A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 8A
Voltage - Forward (Vf) (Max) @ If 680mV @ 8A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 70μA @ 100V
Mounting SMD (SMT)
Case / Package TO-277A (SMPC)
Operating Temperature - Junction -40°C to 150°C
Win Source Part Number 036218-V8P10-M3/86A
Family Name V8P10
Introduction Date September 17, 2006
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian V8P10-M3/86A CAD Model

Description

The Vishay V8P10-M3/86A is a high popularity Schottky diode with a voltage rating of 100V and an average rectified current of 8A.

  • Voltage Rating: 100V
  • Average Rectified Current: 8A
  • Forward Voltage: 680mV @ 8A
  • Reverse Leakage Current: 70μA @ 100V
  • Recovery Speed: Fast Recovery
  • Maximum Frequency: 200mA (Io)
  • Package: TO-277A (SMPC)
  • Compliance: Halogen-free standards
  • Supply and Demand Status: Limited
  • Alternative Parts: V8P10HM3/86A, V8P10HM3/87A, and V8P10HE3/86A
