V20WM100C-M3/I Real Image V20WM100C-M3/I Real Image1 V20WM100C-M3/I Real Image2
Same model may have multiple batches, images only for reference.
V20WM100C-M3/I Real Image V20WM100C-M3/I Real Image1 V20WM100C-M3/I Real Image2
V20WM100C-M3/I Real Image V20WM100C-M3/I Real Image1 V20WM100C-M3/I Real Image2
Same model may have multiple batches, images only for reference.

V20WM100C-M3/I

Part No V20WM100C-M3/I
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE SCHOTTKY 20A 100V DPAK / Diode Array 1 Pair Common Cathode Schottky 100 V 10A Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63
Datasheet
V20WM100C-M3/I Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Diodes - Rectifiers - Arrays
Mfr Vishay General Semiconductor - Diodes Division
Series TMBS®
Package Tape & Reel
Product Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) (per Diode) 10A
Voltage - Forward (Vf) (Max) @ If 820 mV @ 10 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 800 µA @ 100 V
Operating Temperature - Junction -40°C ~ 150°C
Mounting SMD (SMT)
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package D-PAK (TO-252AA)
Base Product Number V20WM100
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Names V20WM100C-M3/IGICT,V20WM100C-M3/IGITR,V20WM100C-M3/IGIDKR,V20WM100C-M3/I-ND
Standard Package 2,500
Win Source Part Number 979138-V20WM100C-M3/I
Ultra Librarian 3D Model Ultra Librarian V20WM100C-M3/I CAD Model

Description

The Vishay General Semiconductor - Diodes Division V20WM100C-M3/I is a Schottky diode that comes in a TO-252-3, DPak (2 Leads + Tab), SC-63 package.

  • Voltage - DC Reverse (Vr) (max): 100 V
  • Voltage - Forward (Vf) (max) @ If: 820 mV @ 10 A
  • Diode Configuration: 1 Pair Common Cathode
  • Current - Average Rectified (Io) (per Diode): 10A
  • Operating Temperature - Junction: -40°C ~ 150°C
  • Series: TMBS®
  • Recovery Speed: =< 500ns, > 200mA (Io)
  • Package: Tape & Reel
  • Standard Package: 2,500
  • Supplier Device Package: D-PAK (TO-252AA)
  • MSL Level: 1 (Unlimited)
  • REACH: Unaffected
  • HTSUS: 8541.10.0080
