TCMT4600 Real Image TCMT4600 label picture TCMT4600 real image7166 TCMT4600 Real Image1 TCMT4600 Real Image2
Same model may have multiple batches, images only for reference.
TCMT4600 Real Image TCMT4600 label picture TCMT4600 real image7166 TCMT4600 Real Image1 TCMT4600 Real Image2
TCMT4600 Real Image TCMT4600 label picture TCMT4600 real image7166 TCMT4600 Real Image1 TCMT4600 Real Image2
Same model may have multiple batches, images only for reference.

TCMT4600

Part No TCMT4600
Manufacturer Vishay
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optocoupler AC-IN 4-CH Transistor DC-OUT 16-Pin SOP / OPTOISO 3.75KV 4CH TRANS 16-SOP
Datasheet
TCMT4600 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Vishay
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 80% @ 5mA
Maximum DC Current Transfer Ratio 300% @ 5mA
Switching Turn-On and Turn-Off Time 6μs, 5μs
Rise and Fall Time 3μs, 4.7μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 70V
Channel Output Current 50mA
Forward Voltage 1.35V
Continuous forward current- Max 60mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 16-SOP
Win Source Part Number 032046-TCMT4600
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Communications & Networking
Family Name TCMT4600
Introduction Date November 20, 2003
ECCN EAR99
Country of Origin China, Malaysia
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian TCMT4600 CAD Model

Description

The Vishay electronic component, with a Win Source Part Number of 032046-TCMT4600, is an Isolator.

  • Packaging: Reel - TR
  • Mounting: SMD (SMT)
  • Output Type: Transistor
  • Forward Voltage: 1.35V
  • Input Type: AC, DC
  • Number of Channels: 4
  • Vce Saturation (Max): 300mV
  • Isolation Voltage: 3750Vrms
  • Family: TCMT4600
  • Category: Isolators
  • Status: Active
  • Operating Temperature: -40°C to 100°C
  • Case / Package: 16-SOP
  • Minimum DC Current Transfer Ratio: 80% @ 5mA
  • Maximum DC Current Transfer Ratio: 300% @ 5mA
  • Switching Turn-On Time: 6μs
  • Switching Turn-Off Time: 5μs
  • Rise Time: 3μs
  • Fall Time: 4.7μs
  • Maximum Output Voltage: 70V
  • Channel Output Current: 50mA
  • Continuous forward current- Max: 60mA
  • Alternative Parts (Cross-Reference): CNC7H001; TLP290-4(GB,E(O; PS2805-4; TLP290-4(V4-TP,E(T
  • Introduction Date: November 20, 2003
  • ECCN: EAR99
  • Country of Origin: China, Malaysia
  • Estimated EOL Date: 2025
  • Halogen Free: Compliant
  • Supply and Demand Status: Balance
