TCMT1109 Real Image TCMT1109 real image7161 TCMT1109 real image7162
Same model may have multiple batches, images only for reference.
TCMT1109 Real Image TCMT1109 real image7161 TCMT1109 real image7162
TCMT1109 Real Image TCMT1109 real image7161 TCMT1109 real image7162
Same model may have multiple batches, images only for reference.

TCMT1109

Part No TCMT1109
Manufacturer Vishay
Catalog Optoisolators - Transistor, Photovoltaic Output
Description DC-IN 1-CH Transistor DC-OUT 4-Pin SSOP T/R / OPTOISOLATOR 3.75KV TRANS 4-SOP
Datasheet
TCMT1109 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Vishay
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 200% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Switching Turn-On and Turn-Off Time 9.5μs, 8.5μs
Rise and Fall Time 5.5μs, 7μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 70V
Channel Output Current 50mA
Forward Voltage 1.35V
Continuous forward current- Max 60mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SOP
Win Source Part Number 032043-TCMT1109
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Communications & Networking, Consumer Electronics
Family Name TCMT1103
Introduction Date November 19, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian TCMT1109 CAD Model

Description

The Vishay TCMT1109 optoisolator is a transistor output type with an isolation voltage of 3750Vrms.

  • Forward Voltage: 1.35V
  • Input Type: DC
  • Number of Channels: 1
  • Vce Saturation (Max): 300mV
  • Minimum DC Current Transfer Ratio: 200% @ 5mA
  • Maximum DC Current Transfer Ratio: 400% @ 5mA
  • Switching Turn-On Time: 9.5μs
  • Switching Turn-Off Time: 8.5μs
  • Rise Time: 5.5μs
  • Fall Time: 7μs
  • Maximum Output Voltage: 70V
  • Channel Output Current: 50mA
  • Continuous Forward Current: maximum 60mA
  • Package Type: 4-SOP
  • Mounting: SMD (SMT)
  • Category: isolators
  • Status: active
  • Supply and Demand Status: balanced
