LL103A-GS18 Vishay LL103A-GS18 Real Image LL103A-GS18 label picture
Same model may have multiple batches, images only for reference.
LL103A-GS18 Vishay LL103A-GS18 Real Image LL103A-GS18 label picture
LL103A-GS18 Vishay LL103A-GS18 Real Image LL103A-GS18 label picture
Same model may have multiple batches, images only for reference.

LL103A-GS18

Part No LL103A-GS18
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 200MA SOD80 / Diode Small Signal Schottky 40V 0.2A Automotive 2-Pin Mini-MELF SOD-80 T/R
Datasheet
LL103A-GS18 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 200mA
Voltage - Forward (Vf) (Max) @ If 600mV @ 200mA
Reverse Recovery Time (trr) 10ns
Current - Reverse Leakage @ Vr 5μA @ 30V
Capacitance @ Vr, F 50pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-80 MiniMELF
Operating Temperature - Junction 125°C (Max)
Win Source Part Number 070988-LL103A-GS18
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LL103A
Introduction Date April 02, 1998
ECCN EAR99
Country of Origin China
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian LL103A-GS18 CAD Model

Description

The Vishay LL103A-GS18 is a Schottky Diode with a Voltage - DC Reverse (Vr) (Max) of 40V and a Current - Average Rectified (Io) of 200mA.

  • Forward Voltage: The diode has a Voltage - Forward (Vf) (Max) @ If of 600mV @ 200mA and a Reverse Recovery Time (trr) of 10ns.
  • Reverse Leakage Current: The device has a Current - Reverse Leakage @ Vr of 5μA @ 30V and a Capacitance @ Vr, F of 50pF @ 0V, 1MHz.
  • Package: The LL103A-GS18 is packaged in a SOD-80 MiniMELF case and is suitable for use in Discrete Semiconductor Products.
