IHLP2525CZERR68M01 Real Image IHLP2525CZERR68M01 real image
IHLP2525CZERR68M01 Real Image IHLP2525CZERR68M01 real image
Same model may have multiple batches, images only for reference.

IHLP2525CZERR68M01

Part No IHLP2525CZERR68M01
Manufacturer Vishay
Catalog Fixed Inductors
Description FIXED IND 680NH 15.5A 5.5 MOHM
Datasheet
IHLP2525CZERR68M01 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Molded
Inductance 680nH
Tolerance ±20%
Current Rating 15.5A
Current - Saturation 25A
DC Resistance (DCR) 5.5 mOhm Max
Temperature Range - Operating -55°C to 125°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.118" (3.00mm)
Win Source Part Number 017182-IHLP2525CZERR68M01
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 2k pcs
Ultra Librarian 3D Model Ultra Librarian IHLP2525CZERR68M01 CAD Model

Description

The Vishay IHLP2525CZERR68M01 is a molded inductor with a current rating of 15.5A and an inductance of 680nH.

  • Height: 0.118" (3.00mm)
  • Tolerance: ±20%
  • Current Saturation: 25A
  • Frequency Test: 100kHz
  • DC Resistance (DCR): 5.5 mOhm Max
  • Operating Temperature Range: -55°C to 125°C
  • Popularity: High
  • Supply and Demand Status: Balanced
  • Package Contains: 2k pcs
