Same model may have multiple batches, images only for reference.

IHLP2525CZER220M11

Name: IHLP2525CZER220M11
Brand: Vishay
SKU: 156164
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IHLP2525CZER220M11
Manufacturer	Vishay
Catalog	Fixed Inductors
Description	FIXED IND 22UH 2.9A 135 MOHM SMD
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Inductors, Coils, Chokes
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Type	Molded
Material - Core	Powdered Iron
Inductance	22μH
Tolerance	±20%
Current Rating	2.9A
Current - Saturation	2.5A
DC Resistance (DCR)	135 mOhm Max
Temperature Range - Operating	-55°C to 125°C
Frequency - Test	100kHz
Mounting	SMD (SMT)
Height - Seated (Max)	0.118" (3.00mm)
Win Source Part Number	111929-IHLP2525CZER220M11
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IHLP2525CZER220M11 CAD Model

Alternative Products

Description

The Vishay IHLP2525CZER220M11 is a molded inductor that is commonly used in various electronic devices.

Current Rating: 2.9A
Inductance: 22μH
Height: 0.118" (3.00mm)
Device: surface-mount device
Tolerance: ±20%
Core Material: powdered iron
Current Saturation: 2.5A
Test Frequency: 100kHz
DC Resistance (DCR): 135 mOhm Max
Supply and demand status: balanced
