Same model may have multiple batches, images only for reference.
112CNQ030ASM Real Image
Same model may have multiple batches, images only for reference.

112CNQ030ASM

Part No 112CNQ030ASM
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 30V D618SM / Diode Array 1 Pair Common Cathode Schottky 30 V 55A Through Hole D-61-8-SM
Datasheet
112CNQ030ASM Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Diodes - Rectifiers - Arrays
Mfr Vishay General Semiconductor - Diodes Division
Package Bulk
Product Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30 V
Current - Average Rectified (Io) (per Diode) 55A
Voltage - Forward (Vf) (Max) @ If 490 mV @ 55 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 3.5 mA @ 30 V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Type Through Hole
Package / Case D-61-8-SM
Supplier Device Package D-61-8-SM
Base Product Number 112CNQ030
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Names *112CNQ030ASM
Standard Package 400
Win Source Part Number 994039-112CNQ030ASM
Ultra Librarian 3D Model Ultra Librarian 112CNQ030ASM CAD Model

Description

This electronic component, with a Win Source Part Number of 994039-112CNQ030ASM, is a Schottky diode rectifier array.

  • Win Source Part Number: 994039-112CNQ030ASM
  • Component Type: Schottky Diode Rectifier Array
  • Recovery Speed: Fast, less than 500ns
  • Forward Voltage (Max): 490 mV @ 55 A
  • Reverse Leakage Current: 3.5 mA @ 30 V
  • Junction Temperature Range: -55°C to 150°C
  • Diode Configuration: 1 pair common cathode
