Same model may have multiple batches, images only for reference.
EKXJ451ELL560MM25S United Chemi-Con
Same model may have multiple batches, images only for reference.

EKXJ451ELL560MM25S

Part No EKXJ451ELL560MM25S
Manufacturer United Chemi-Con
Catalog Aluminum Capacitors
Description CAP ALUM 56UF 20% 450V RADIAL / 56 µF 450 V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr United Chemi-Con
Series KXJ
Package Bulk
Product Status Active
Capacitance 56 µF
Tolerance ±20%
Voltage - Rated 450 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 12000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Ratings AEC-Q200
Applications Automotive
Ripple Current @ Low Frequency 560 mA @ 120 Hz
Ripple Current @ High Frequency 1.4 A @ 100 kHz
Lead Spacing 0.295" (7.50mm)
Size / Dimension 0.709" Dia (18.00mm)
Height - Seated (Max) 1.043" (26.50mm)
Surface Mount Land Size -
Mounting Type Through Hole
Package / Case Radial, Can
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1358204-EKXJ451ELL560MM25S
Ultra Librarian 3D Model Ultra Librarian EKXJ451ELL560MM25S CAD Model

Description

The 1358204-EKXJ451ELL560MM25S is a high-quality aluminum electrolytic capacitor manufactured by United Chemi-Con. It belongs to the KXJ series and has a capacitance of 56 μF with a tolerance of ±20%.

  • Capacitance: 56 μF
  • Tolerance: ±20%
  • Rated Voltage: 450 V
  • Ripple Current (Low Frequency): 560 mA @ 120 Hz
  • Ripple Current (High Frequency): 1.4 A @ 100 kHz
  • Package: Radial, can
  • Mounting Type: Through-hole
  • Diameter: 0.709 inches (18.00 mm)
  • Maximum Seated Height: 1.043 inches (26.50 mm)
  • Lifetime: 12,000 hours @ a temperature of 105°C
  • Standard: AEC-Q200
  • REACH: Compliant
