UM3670A Union Semiconductor
Same model may have multiple batches, images only for reference.

UM3670A

Part No UM3670A
Manufacturer Union Semiconductor
Catalog Misc Products
Description High Speed, Low Voltage, Dual, DPDT Analog Switch
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Uncategorized
Manufacturer Union Semiconductor
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 841344-UM3670A
Package Tape & Reel (TR)
Product Status Active
Switch Circuit DPDT - NO/NC
Multiplexer/Demultiplexer Circuit 2:2
Number of Circuits 2
On-State Resistance (Max) 10 Ohm
Voltage - Supply, Single (V+) 1.8 V ~ 5.5 V
Switch Time (Ton, Toff) (Max) 20ns, 10ns
-3db Bandwidth 300MHz
Channel Capacitance (CS(off), CD(off)) 9pF, 9pF
Crosstalk -60dB @ 10MHz
Operating Temperature -40°C ~ 85°C
Grade -
Mounting Type Surface Mount
Package / Case 16-UFQFN
Supplier Device Package 16-QFN (2.6x1.8)
Ultra Librarian 3D Model Ultra Librarian UM3670A CAD Model

Description

The supply and demand status for this product is currently balanced. The UM3670A is a high-performance, low-power, and low-voltage regulator. It features a wide input voltage range and a low dropout voltage. This product is ideal for use in applications such as battery-powered devices, portable equipment, and automotive electronics.
