The ESD24V32D-LC is a Transient Voltage Suppressor (TVS) diode designed to protect sensitive electronic components from electrostatic discharge (ESD) and other transient voltage events. Manufactured by UN Semiconductor INC, this device is specifically engineered to safeguard data and power lines in applications requiring a higher standoff voltage. The 'LC' designation indicates a low capacitance, making it suitable for high-speed data lines.

Applications:

• Industrial Equipment: Protection of control and communication lines in industrial environments where higher voltage surges are possible.
• Telecom Equipment: Safeguarding telecom interfaces from ESD and voltage transients.
• Power Supplies: Providing protection for power input lines in various electronic devices.
• Automotive Electronics: Protecting sensitive components in automotive systems from ESD.
• High-Voltage Data Lines: Protecting data lines where higher voltage signals are present.

Features:

• Low Clamping Voltage: Provides effective protection by clamping transient voltages to a safe level.
• Fast Response Time: Quickly responds to transient events, minimizing the risk of damage to protected components.
• Low Capacitance: Ensures signal integrity in high-speed data lines.
• Small Package Size: Allows for easy integration into compact electronic devices.
• RoHS Compliant: Complies with Restriction of Hazardous Substances (RoHS) directive.

Benefits:

• Enhanced ESD Protection: Effectively protects sensitive electronic components from ESD damage, improving product reliability.
• Improved System Reliability: Reduces the risk of system failures due to transient voltage events.
• Minimized Downtime: Prevents equipment downtime and repair costs associated with ESD damage.
• Increased Product Lifespan: Extends the lifespan of electronic devices by protecting them from voltage transients.
• High Stand-off Voltage: Specifically designed for applications requiring protection against higher voltage transients.

Additional Details:

The ESD24V32D-LC has a typical breakdown voltage of 26V and a low capacitance suitable for high-speed data lines. It's designed for applications requiring a higher standoff voltage than lower voltage TVS diodes. The small package and RoHS compliance make it suitable for modern electronic devices requiring ESD protection. This TVS diode provides an effective solution for protecting against electrostatic discharge in systems with higher voltage requirements, enhancing overall reliability and extending product lifespan.

This part is listed as END-OF-LIFE by the manufacturer. Consider availability when designing this part into new products.
