HM78D-128330MLFTR

Part No HM78D-128330MLFTR
Manufacturer TT Electronics
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 33UH SMD
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Number of Coils 2
Inductance - Connected In Parallel 33 µH
Inductance - Connected In Series 132 µH
Tolerance ±20%
Current Rating - Parallel 4.2 A
Current Rating - Series 1.7 A
Current Saturation - Parallel 5.6 A
Current Saturation - Series 3.1 A
DC Resistance (DCR) - Parallel 75mOhm
DC Resistance (DCR) - Series 300mOhm
Shielding Shielded
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Case / Package Nonstandard
Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height 0.317\
Package Cut Tape (CT)
Supply and Demand Status Shortage
Win Source Part Number 1530699-HM78D-128330MLFTR
Ultra Librarian 3D Model Ultra Librarian HM78D-128330MLFTR CAD Model

Description

N
