84XR20KLF TT Electronics
Same model may have multiple batches, images only for reference.

84XR20KLF

Part No 84XR20KLF
Manufacturer TT Electronics
Catalog Trimmer Potentiometers
Description TRIMMER 20K OHM 0.25W GW SIDE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer TT Electronics/BI
Resistance 20 kOhms
Power (Watts) 0.25W, 1/4W
Tolerance ±10%
Temperature Coefficient ±100ppm/°C
Number of Turns 12
Adjustment Type Side Adjustment
Resistive Material Cermet
Mounting Style SMD
Termination Style Gull Wing
Dimension Rectangular - 0.290" x 0.250" Face x 0.295" H (7.37mm x 6.35mm x 7.49mm)
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 810825-84XR20KLF
Ultra Librarian 3D Model Ultra Librarian 84XR20KLF CAD Model

Description

The TT Electronics/BI 810825-84XR20KLF is a surface mount cermet potentiometer from TT Electronics/BI.

  • Resistance: 20 kOhms
  • Power Rating: 0.25W
  • Tolerance: ±10%
  • Temperature Coefficient: ±100ppm/°C
  • Turns: 12
  • Adjustment: Side
  • Package Dimensions: Rectangular (0.290" x 0.250" face, 0.295" height)
  • Manufacturer Pack Quantity: 50
  • MSL Level: 1 (Unlimited)
