Same model may have multiple batches, images only for reference.
CMT-8118 Triad Magnetics – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

CMT-8118

Part No CMT-8118
Manufacturer Triad Magnetics
Catalog Common Mode Chokes
Description CMC 7.3MH 9.3A 2LN THROUGH HOLE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 7.3 mH @ 1 kHz
Current Rating (Max) 9.3A
DC Resistance (DCR) (Max) 32mOhm
Voltage Rating - AC 1500V (1.5kV)
Temperature Range - Operating -55°C ~ 105°C
Approval Agency CSA, IEC, UL, VDE
Mounting Type Through Hole
Size / Dimension 1.650" L x 0.800" W (41.91mm x 20.32mm)
Height (Max) 1.650" (41.91mm)
Case / Package Vertical, 4 PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1530485-CMT-8118
Ultra Librarian 3D Model Ultra Librarian CMT-8118 CAD Model
