The TEM2-2422 is a 2-Watt isolated DC-DC converter module from TRACO Power. It's designed to provide a regulated output voltage from a DC input, with electrical isolation between the input and output. This converter is suitable for a wide range of applications requiring electrical isolation and voltage conversion.

Applications:

• Industrial automation: Providing isolated power for sensors, actuators, and control systems.
• Instrumentation: Isolating measurement circuits from power supplies to improve accuracy and safety.
• Medical equipment: Providing isolated power for patient monitoring and diagnostic equipment.
• Telecommunications: Supplying isolated power for communication interfaces and network devices.
• Transportation: Powering electronic systems in vehicles and trains with electrical isolation.

Features:

• 2-Watt output power: Delivers sufficient power for a variety of low-power applications.
• Isolated output: Provides electrical isolation between input and output, protecting sensitive circuits.
• Wide input voltage range: Accepts a wide range of DC input voltages.
• Regulated output voltage: Provides a stable and accurate output voltage.
• Short-circuit protection: Protects the converter and connected circuits from damage due to short circuits.

Benefits:

• Improved safety: Electrical isolation protects users and equipment from hazardous voltages.
• Enhanced noise immunity: Isolation reduces noise coupling between input and output circuits.
• Flexible power solutions: Wide input voltage range allows for use in various power systems.
• Stable performance: Regulated output voltage ensures consistent operation of connected devices.
• Reliable operation: Built-in protection features enhance the overall system reliability.

Technical Specifications:

The TEM2-2422 features a 24V nominal input voltage with a range, likely encompassing standard 24V industrial supplies. It provides dual outputs of +12V and -12V. The isolation voltage is typically in the range of several kilovolts DC. The output current depends on the output voltage, with a maximum total output power of 2 Watts. It features short-circuit protection and over-temperature protection. The operating temperature range is usually from -40°C to +85°C. The package is designed for PCB mounting. Detailed electrical characteristics, including input current, output voltage accuracy, and ripple and noise specifications, are available in the TRACO Power datasheet. The isolation is crucial for safety and for breaking ground loops that can cause noise problems. The converter is suitable for a wide range of industrial and medical applications.
