The TPCA8059-H is a sophisticated N-channel power MOSFET from Toshiba Semiconductor and Storage, designed for high-efficiency power management in a variety of applications. This device features a low drain-source on-resistance (RDS(ON)), which minimizes power loss during switching, leading to improved energy efficiency. The MOSFET is fabricated using advanced trench gate technology, contributing to its superior performance and reliability.

Applications

• DC-DC converters
• Load switching
• Power management circuits in portable devices
• Motor control applications
• LED lighting systems

Features

• Low drain-source on-resistance (RDS(ON)) for reduced power loss
• High-speed switching capability for efficient operation
• Advanced trench gate structure for enhanced performance
• Optimized for 4.5V gate drive
• Available in a small surface-mount package for space-saving designs
• Pb-free and RoHS compliant

Benefits

• Improved energy efficiency in power conversion systems
• Reduced heat generation, enhancing system reliability
• Compact design for space-constrained applications
• Simplified thermal management due to low RDS(ON)
• Meets environmental regulations

Additional Details

The TPCA8059-H typically features a maximum drain-source voltage (VDSS) of 30V and a continuous drain current (ID) of up to 12A, depending on the specific application and thermal conditions. Its gate-source voltage (VGSS) is rated at ±20V. The device's low gate charge (Qg) contributes to its fast switching speed. The operating and storage temperature range is typically between -55°C and 150°C. The RDS(ON) is typically specified at 9.0 mΩ at VGS = 10V, and 14.0 mΩ at VGS = 4.5V. The package is typically SOP-8. These characteristics make the TPCA8059-H well-suited for battery-powered devices and other applications where efficiency and size are critical. Its robust design ensures reliable operation in demanding environments.
