TLP290 Toshiba Semiconductor and Storage TLP290 real image7466 TLP290 Real Image1 TLP290 Real Image2 TLP290 Real Image3
Same model may have multiple batches, images only for reference.
TLP290 Toshiba Semiconductor and Storage TLP290 real image7466 TLP290 Real Image1 TLP290 Real Image2 TLP290 Real Image3
TLP290 Toshiba Semiconductor and Storage TLP290 real image7466 TLP290 Real Image1 TLP290 Real Image2 TLP290 Real Image3
Same model may have multiple batches, images only for reference.

TLP290

Part No TLP290
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLTR 2.5KV 4CH TRANS 16-SO
Datasheet
TLP290 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 50% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 16-SO
Win Source Part Number 213039-TLP290
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TLP290 CAD Model

Description

The Toshiba Semiconductor and Storage TLP290 is a 4-channel transistor output type isolator that is mounted using SMD (SMT) technology.

  • Forward Voltage: 1.2V
  • Isolation Voltage: 2500Vrms
  • Minimum DC Current Transfer Ratio: 50% @ 5mA
  • Maximum DC Current Transfer Ratio: 400% @ 5mA
  • Switching Turn-On and Turn-Off Time: 3μs
  • Rise and Fall Time: 2μs and 3μs
  • Maximum Output Voltage: 80V
  • Channel Output Current: 50mA
  • Supply and Demand Status: limited
