TB6568KQ Real Image TB6568KQ real image7042 TB6568KQ Real Image1 TB6568KQ Real Image2 TB6568KQ Real Image3
Same model may have multiple batches, images only for reference.
TB6568KQ Real Image TB6568KQ real image7042 TB6568KQ Real Image1 TB6568KQ Real Image2 TB6568KQ Real Image3
TB6568KQ Real Image TB6568KQ real image7042 TB6568KQ Real Image1 TB6568KQ Real Image2 TB6568KQ Real Image3
Same model may have multiple batches, images only for reference.

TB6568KQ

Part No TB6568KQ
Manufacturer Toshiba Semiconductor and Storage
Catalog PMIC - Motor Drivers, Controllers
Description IC MOTOR DRIVER PAR 7HSIP
Datasheet
TB6568KQ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Toshiba Semiconductor and Storage
Packaging Tray
Status Active
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Bi-CMOS
Applications General Purpose
Output Current 1.5A
Supply Voltage - Operating 10 V to 45 V
Voltage - Load 10 V to 45 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting Through Hole
Case / Package 7-HSIP
Win Source Part Number 212583-TB6568KQ
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TB6568KQ
ECCN EAR99
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian TB6568KQ CAD Model

Description

The Toshiba Semiconductor and Storage TB6568KQ is a fully integrated driver and control power stage for brushed DC motors.

  • Technology: Bi-CMOS technology
  • Step Resolution: -
  • Output Current: 1.5A
  • Voltage Load: 10V to 45V
  • Operating Temperature Range: -40°C to 85°C
  • Case/Package: 7-HSIP
  • Supply Voltage: 10V to 45V
  • Description: It is a common-used part that can be cross-referenced with L6225PDTR, L6225PD, and E-L6207PD.
