TB6561FG(EL)

Part No TB6561FG(EL)
Manufacturer Toshiba Semiconductor and Storage
Catalog PMIC - Motor Drivers, Controllers
Description IC MOTOR DRIVER PAR 30SSOP
Datasheet
TB6561FG(EL) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Bi-CMOS
Applications General Purpose
Output Current 1.5A
Supply Voltage - Operating 10 V to 36 V
Voltage - Load 10 V to 36 V
Temperature Range - Operating -20°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 30-SSOP
Win Source Part Number 212582-TB6561FG(EL)
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TB6561FG(EL) CAD Model

Description

The Toshiba Semiconductor and Storage TB6561FG(EL) is a fully integrated driver control and power stage component that comes under the Integrated Circuits category.

  • Popularity: medium popularity component
  • Supply and Demand Status: limited supply and demand status.
  • Technology: Bi-CMOS technology
  • Operating Temperature: -20°C to 85°C (TA).
  • Output Current: 1.5A
  • Voltage Load: 10 V to 36 V.
  • Suitable For: general-purpose applications
  • Mounting: using SMD (SMT) technology.
