The USBN9604-28MX is a versatile and high-performance USB Node Controller with integrated transceiver and Serial Interface Engine (SIE) from Texas Instruments. This advanced IC is specifically designed to provide a straightforward and efficient solution for adding USB functionality to a wide range of applications, including but not limited to, embedded systems, computer peripherals, and communication devices.

Key Features

• Integrated USB Transceiver: The device features a full-speed transceiver that is compliant with USB 1.1 specifications, ensuring reliable data transfer at speeds up to 12 Mbps.
• Serial Interface Engine (SIE): The SIE handles low-level USB protocol details, allowing for easier implementation and management of USB communications.
• Flexible Interface Options: The USBN9604-28MX supports multiple interface options, including a General-Purpose Interface Bus (GPIB) that allows for seamless integration with a variety of microcontrollers and processors.
• Low Power Consumption: Designed for power-sensitive applications, the device operates efficiently with minimal power requirements, making it ideal for portable and battery-powered devices.
• Enhanced Functionality: It includes features such as endpoint FIFOs, suspend/resume logic, and a clock recovery system, which contribute to its robust performance and reliability.

Applications

The USBN9604-28MX is suitable for a broad range of applications that require USB connectivity. Its compact form factor and comprehensive feature set make it an excellent choice for:

• Industrial Control Systems
• Medical Devices
• Point-of-Sale Terminals
• Data Acquisition Systems
• PC Peripherals
• Networking Equipment

Technical Specifications

The device is available in a 28-pin SSOP package and operates over a temperature range of 0°C to 70°C. It requires a single 3.3V power supply for the core and can handle 5V tolerant I/Os, making it compatible with a range of external components.

In conclusion, the USBN9604-28MX from Texas Instruments is a highly integrated and efficient solution for implementing USB connectivity in a multitude of electronic devices. Its ease of use, combined with Texas Instruments' reputation for quality and support, makes it a top choice for designers and engineers worldwide.
